FEATURES
Miniature size
Collimated straight beam
Adjustible focuse
Easy use & maintenance free
Longlife operation
High efficiency
High reliability
APPLICATIONS
Thermal printing Material Inspection Scanning Biochemistry Lidar
Specifications
|
Wavelength |
808(+/-5) nm |
|
Spatial Mode |
multimode |
|
Output Power |
500, 800,…3500mW |
|
Operation Mode |
CW or Modulation |
|
Polarization |
10:1 |
|
Pointing Stability |
<0.05 mrad |
|
Beam Size |
5 mm |
|
Beam Divergence |
3 mrad |
|
Power Stability* |
<±3% per 2 hrs |
|
Beam Height |
25mm |
|
Temperature Stabilizing |
TEC |
|
Warm Up Time |
<5 minutes |
|
Beam Quality (M2) |
<2 |
|
Optimum Operating Temperature |
20~30oc |
|
Storage Temperature |
10~50oC |
|
MTTF** |
10,000 hrs |
|
Modulation |
Modulation |
